DCx Camera Functional Description and SDK Manual
hCam
Camera handle
IMGFRMT_CMD_GET_ARBITRARY_AOI_SUPPORTED
Returns if the sensor supports a free selection of
the area of interest (AOI).
More details
pParam: Pointer to variable of type UINT
indicating if free AOI selection is supported:
0 = No free AOI supported
1 = Free AOI supported
nSizeOfParam: 4
pParam
Pointer to a function parameter, whose function
depends on nCommand.
nSizeOfParam
Size (in bytes) of the memory area to which
pParam refers.
Contents of the IMAGE_FORMAT_LIST list of image formats
UINT
nSizeOfListEntry
Must be preset with the size of a list entry in bytes
UINT
nNumListElements
Must be preset with the number of list entries (from
IMGFRMT_CMD_GET_NUM_ENTRIES)
UINT
nReserved[4]
Reserved
IMAGE_FORMAT_INF
O
FormatInfo[0]
First entry in the list.
After having been filled by IMGFRMT_CMD_GET_LIST,
the list contains additional entries FormatInfo[1]…
FormatInfo[nNumListElements-1].
Contents of the list entry IMAGE_FORMAT_INFO
INT
nFormatID
Format ID of the specified image format (see table
"Image formats" below)
UINT
nWidth
Width of the area of interest
UINT
nHeight
Height of the area of interest
UINT
nX0
Start point of the area of interest (X)
UINT
nY0
Start point of the area of interest (Y)
UINT
nSupportedCaptureModes
Image capture modes supported for this format (see
table below)
UINT
nBinningMode
Binning mode used
UINT
nSubsamplingMode
Subsampling mode used
IS_CHAR
strFormatName[64]
Description of the format
double
dSensorScalerFactor
Scaling factor used (only sensors that support
scaling).
UINT
nReserved[24]
Reserved
Possible values for CAPTUREMODE
CAPTMODE_SINGLE
Freerun mode, single frame (freerun snap)
CAPTMODE_FREERUN
Freerun mode, continuous (freerun live)
CAPTMODE_TRIGGER_SOFT_SINGLE
Software triggered mode, single frame
