© 2016 Thorlabs Scientific Imaging294
DCx Camera Functional Description and SDK Manual
Example 5
INT nRet = IS_SUCCESS;
IO_FLASH_PARAMS flashParams;
// Get the minimum values for flash delay and flash duration
nRet = is_IO(m_hCam, IS_IO_CMD_FLASH_GET_PARAMS_MIN,
(void*)&flashParams, sizeof(flashParams));
if (nRet == IS_SUCCESS)
{
INT nFlashDelayMin = flashParams.s32Delay;
UINT nFlashDurationMin = flashParams.u32Duration;
}
// Get the maximum values for flash delay and flash duration
nRet = is_IO(m_hCam, IS_IO_CMD_FLASH_GET_PARAMS_MAX,
(void*)&flashParams, sizeof(flashParams));
if (nRet == IS_SUCCESS)
{
INT nFlashDelayMax = flashParams.s32Delay;
UINT nFlashDurationMax = flashParams.u32Duration;
}
// Get the increment for flash delay and flash duration
nRet = is_IO(m_hCam, IS_IO_CMD_FLASH_GET_PARAMS_INC,
(void*)&flashParams, sizeof(flashParams));
if (nRet == IS_SUCCESS)
{
UINT nFlashDelayInc = flashParams.s32Delay;
UINT nFlashDurationInc = flashParams.u32Duration;
}
// Get the current values for flash delay and flash duration
nRet = is_IO(m_hCam, IS_IO_CMD_FLASH_GET_PARAMS,
(void*)&flashParams, sizeof(flashParams));
if (nRet == IS_SUCCESS)
{
INT nCurrentFlashDelay = flashParams.s32Delay;
UINT nCurrentFlashDuration = flashParams.u32Duration;
}
// Set the current values for flash delay and flash duration
nRet = is_IO(m_hCam, IS_IO_CMD_FLASH_SET_PARAMS,
(void*)&flashParams, sizeof(flashParams));
Example 6
INT nRet = IS_SUCCESS;
// Get all GPIOs that can be used as flash output
UINT nGPIOs_Flash = 0;
INT nRet = is_IO(m_hCam, IS_IO_CMD_FLASH_GET_SUPPORTED_GPIOS,
(void*)&nGPIOs_Flash, sizeof(nGPIOs_Flash));
// Get all GPIOs that can be used for the PWM
UINT nGPIOs_PWM = 0;
INT nRet = is_IO(m_hCam, IS_IO_CMD_PWM_GET_SUPPORTED_GPIOS,
(void*)&nGPIOs_PWM, sizeof(nGPIOs_PWM));
Example 7
INT nRet = IS_SUCCESS;
// Disable flash
UINT nMode = IO_FLASH_MODE_OFF;
nRet = is_IO(m_hCam, IS_IO_CMD_FLASH_SET_MODE, (void*)&nMode, sizeof(nMode));
