DCx Camera Functional Description and SDK Manual
hCam
Camera handle
Control parameters
pval1 = 1 enables control, 0 disables control
IS_GET_ENABLE_AUTO_FRAMERATE
Returns the current auto frame rate setting.
Control parameters
pval1: returns the current setting
IS_SET_ENABLE_AUTO_SENSOR_FRAMERATE
Enables/disables the sensor's internal auto frame
rate function
*1
Control parameters
pval1 = 1 enables control, 0 disables control
IS_GET_ENABLE_AUTO_SENSOR_FRAMERATE
Returns the sensor's current auto frame rate
setting
*1
Control parameters
pval1: returns the current setting
Adjusting auto gain control/auto exposure shutter
IS_SET_AUTO_REFERENCE
Sets the setpoint for auto gain control/auto
exposure shutter.
Control parameters
pval1: defines the setpoint (average brightness
of the image); the following rule applies
independently of the image bit depth:
0 = black
128 = 50% gray (default)
255 = white
Note on the sensor's internal control
functionality
When using the sensor's internal control
functionality, you can only used values in a range
between [44...235]. The increment in this range is
4. Smaller values are automatically set to 44,
larger values to 235.
IS_GET_AUTO_REFERENCE
Returns the set point for auto gain control/auto
exposure shutter.
Control parameters
pval1: returns the current setting
IS_SET_AUTO_GAIN_MAX
Sets the upper limit for auto gain control.
Control parameters
pval1: valid value for gain (0...100)
IS_GET_AUTO_GAIN_MAX
Returns the upper limit for auto gain control.
Control parameters
pval1: returns the current setting
IS_SET_AUTO_SHUTTER_MAX
Sets the upper limit for auto exposure shutter.
Control parameters
pval1: valid exposure value (0 sets the value
continuously to max. exposure)
