THORLABS DCC1645C Description And Sdk Manual

© 2016 Thorlabs Scientific Imaging
5 Specifications
449
Color: AOI position grid
horizontal, vertical
Pixels
2, 2
AOI frame rate, 800 x 600 pixels
(SVGA)
fps
37
AOI frame rate, 640 x 480 pixels
(VGA)
fps
45
AOI frame rate, 320 x 240 pixels
(CIF)
fps
78
Binning
Mode
Vertical
*4
Method
V: Monochrome binning, additive
Factor
2x, 3x, 4x
Frame rate with 2x binning, 1024
x 384 pixels
fps
53
Frame rate with 3x binning, 1024
x 256 pixels
fps
71
Frame rate with 4x binning, 1024
x 192 pixels
fps
85
Subsampling
Mode
-
Hardware trigger
Mode
Asynchronous
Trigger delay with rising edge
µs
39.5 ±2.6
Trigger delay with falling edge
µs
57.9 ±2.6
Additive trigger delay (optional)
µs
15 µs...4 s
Power consumption
*5
W
1.0 to 1.7
*
1
The maximum possible pixel clock frequency depends on the PC hardware used.
*
2
Requires maximum pixel clock frequency.
*
3
Requires minimum pixel clock frequency.
*
4
Use of this function increases the frame rate.
*
5
The power consumption depends on the sensor model and the pixel clock setting.
Please see also the DCU223x Application Notes chapter.
Relative sensor sensitivity
