6 Appendix
493
Parameter
Description
Value range
Example
Height
Height of the AOI
Sensor-dependent
*1
1820
Binning
Activate binning mode and
select factor
Sensor-dependent
*2
0
Subsampling
Activate subsampling
mode and select factor
Sensor-dependent
*2
0
[Scaler]
The internal image scaling is only supported by sensors of the
DCC1240x / DCC3240x camera series.
Mode
Enable/disable scaling
0 = Scaling off
1 = Scaling on
0
Factor
Scaling factor
[Multi AOI]
Enabled
Activate/deactivate multi
AOI
0 = Multi AOI off
1 = Multi AOI on
0
Mode
Mode of multi AOI
Currently only
IS_AOI_MULTI_MODE_AXES
is supported
x1…x4, y1…y4
Axis for multi AOI mode
[Shutter]
Mode
Shutter mode
Sensor-dependent (only
supported by DCC1240x /
DCC3240x models)
1 = Rolling shutter
2 = Global shutter
4 = Fast linescan
64 = Rolling shutter with
global start
128 = Global shutter
(alternative timing)
1
Linscan number
Line which is used in the
linescan mode. The
maximum possible line
number depends on the
height of the selected AOI.
Sensor-dependent (only
supported by DCC1240x /
DCC3240x models)
512
[Log Mode]
Mode
Log mode (only supported
by DCC1240x /
DCC3240x models)
0 = Factory-default with
anti-blooming
1 = Off (no anti-blooming)
2 = Manual Log mode
0
Manual value
Log mode value
Only in combination with
manual Log mode
Manual gain
Log mode gain
[Timing]
Timing parameter settings
Pixelclock
Current pixel clock of the
camera
Sensor-dependent
*1
103
Framerate
Current frame rate
Depends on Pixelclock
15.104458
