© 2019 Thorlabs GmbH
5 Operating Instruction
40
After finishing the measurement, above final screen appears.
Save the numeric test results and the Poincaré Sphere screenshot to a PDF file.
Return to the previous window.
Close the ER Measurement Wizard and return to the PAX1000 GUI.
Please see the Tutorial in the appendix for detailed explanation of the options Compensate El-
lipticity and Compensate DOP .
Please see next section for detailed explanations of the numerical results.
If a warning or an error message appears, please see section Troubleshooting for possible
reasons and solution proposals.
75 76
42
52
