Thytronic Pro-N NVA100X-D - Page 316

316
NVA100X-D - Manual - 02 - 2016
SETTING AND COMMISSIONING
NVA100X-D_menuset4.ai
PREVIOUS SET MENU’
PREVIOUS PROFILE A MENU’
PROCEED SET MENU’
SET
PROFILE A
PROCEED PROFILE A MENU’
55 >>
Common >>
CPhi1<DIR
CosPhi Lag
CPhi1<def enable OFF
CPhi1<def 0.90
tCPhi1<def 1.00 s
CPhi1<BLK1 OFF
CPhi1<BF OFF
Relays CPhi1<
CPhi1<ST-K -
CPhi1<TR-K -
LEDs CPhi1<
CPhi1<ST-L -
CPhi1<TR-L -
CPhi2< DIR
CosPhi Lag
CPhi1<def enable OFF
CPhi2<def 0.90
tCPhi2<def 1.00 s
CPhi2<BLK1 OFF
CPhi2<BF OFF
Relays CPhi2<
CPhi2<ST-K -
CPhi2<TR-K -
LEDs CPhi2<
CPhi2<ST-L -
CPhi2<TR-L -
CB-55 Enable OFF
tARM-CPhi< 1.00 s
CPh1< Element >>
CPh2< Element >>
59V2 >>
U2>def OFF
0.10 En
tU2>def 1.00 s
U2>BLK1 OFF
U2>BF OFF
Relays U2>
U2>ST-K -
U2>TR-K -
LEDs U2>
U2>ST-L -
U2>TR-L -
U2> Element >>
6REF >>
64REF Enable OFF
IREF> OFF
1.00 IEn1
tREF> 1.00 s
64REF-BLK1 OFF
64REF-BLK2OUT OFF
64REF-BF OFF
Relays 64REF
64REF-ST-K -
64REF-TR-K -
LEDs 64REF
64REF-ST-L -
64REF-TR-L -
66 >>
66 Enable OFF
Type66 NST
tC 1 min
NST 10
TST 30 s
TIN 0 min
66BLK1 OFF
Relays 66
66-TR-K -
LEDs 66
66-TR-L -
59N >>
Common >>
U> Enable OFF
Type Characteristic
UE>Curve DEFINITE
tUE>RES 0.00 s
UE>def OFF
0.10 UEn
tUE>def 1.00 s
UE>inv OFF
0.10 UEn
tUE>inv 10.0 s
UE>BLK1 OFF
UE>BF OFF
Relays UE>
UE>ST-K -
UE>TR-K -
LEDs UE>
UE>ST-L -
UE>TR-L -
tUE>>RES 0.00 s
UE>>def OFF
0.10 UEn
tUE>>def 1.00 s
UE>>BLK1 OFF
U>>BF OFF
UE>disbyUE>> OFF
Relays UE>>
UE>>ST-K -
UE>>TR-K -
LEDs UE>>
UE>>ST-L -
UE>>TR-L -
3VoType59N UE
74VTint59N OFF
74VText59N OFF
UE> Element >>
U>> Element >>
59 >>
Common >>
U> Enable OFF
Type Characteristic
U>Curve DEFINITE
U>def enable OFF
U>def 1.00 Un
tU>def 1.00 s
U>inv enable OFF
U>inv 1.00 Un
tU>inv 10.0 s
U>BLK1 OFF
U>BF OFF
Relays U>
U>ST-K -
U>TR-K -
LEDs U>
U>ST-L -
U>TR-L -
U>>def Enable OFF
U>>def 1.00 Un
tU>>def 1.00 s
U>>BLK1 OFF
U>disbyU>> OFF
U>>BF OFF
Relays U>>
U>>ST-K -
U>>TR-K -
LEDs U>>
U>>ST-L -
U>>TR-L -
Utype59 Uph-ph
Logic59 OR
U> Element >>
U>> Element >>
