Thytronic Pro-N NVA100X-D

SETTING AND COMMISSIONING
317
NVA100X-D - Manual - 02 - 2016
NVA100X-D_menuset5.ai
PREVIOUS SET MENU’
PREVIOUS PROFILE A MENU’
PROCEED SET MENU’
SET
PROFILE A
PROCEED PROFILE A MENU’
Common >>
67N >>
IED> Element >>
IED> Enable OFF
Type
Characteristic:
IED>Curve DEFINITE
IEDCLP> Mode OFF
tEDCLP> 0.10 s
tED>RES 0.00 s
IED>def OFF
1.00 IEn2
UED>def 0.100 UEn
ThetaE>def 60 gr
BetaE>def 45 gr
IEDCLP>def 1.50 IEn2
tED>def 1.00 s
IED>inv OFF
1.00 IEn2
UED>inv 0.100 UEn
ThetaE>inv 60 gr
BetaE>inv 45 gr
IEDCLP>inv 1.50 IEn2
tED>inv 10.0 s
IED>BLK1 OFF
IED>BLK2IN OFF
IED>BLK2OUT OFF
IED>BLK4 OFF
IED>BF OFF
Relays IED>
IED>ST-K -
IED>TR-K -
LEDs IED>
IED>ST-L -
IED>TR-L -
IED>> Enable OFF
Type
Characteristic:
IED>>Curve DEFINITE
IEDCLP>> Mode OFF
tEDCLP>> 0.10 s
tED>>RES 0.00 s
IED>>def OFF
1.00 IEn2
UED>>def 0.100 UEn
ThetaE>>def 60 gr
BetaE>>def 45 gr
IEDCLP>>def 1.5 IEn2
tED>>def 1.00 s
IED>>inv OFF
1.00 IEn
UED>>inv 0.100 UEn
ThetaE>>inv 60 gr
BetaE>>inv 45 gr
IEDCLP>>inv 1.5 IEn2
tED>>inv 10.0 s
IED>>BLK1 OFF
IED>>BLK2IN OFF
IED>>BLK2OUT OFF
IED>>BLK4 OFF
IED>>BF OFF
IED>disbyIED>> OFF
Relays IED>>
IED>>ST-K -
IED>>TR-K -
LEDs IED>>
IED>>ST-L -
IED>>TR-L -
IED>>>> Enable OFF
IEDCLP>>>> Mode OFF
tEDCLP>>>> 0.10 s
tED>>>>RES 0.00 s
IED>>>>def OFF
1.00 IEn2
UED>>>>def 0.100 UEn
ThetaE>>>>def 60 gr
BetaE>>>>def 45 gr
IEDCLP>>>>def 1.5 IEn2
tED>>>>def 1.00 s
IED>>>>BLK1 OFF
IED>>>>BLK2IN OFF
IED>>>>BLK2OUT OFF
IED>>>>BLK4 OFF
IED>>>>BF OFF
IED>disIED>>>> OFF
IED>>disIED>>>> OFF
IED>>>disIED>>>> OFF
Relays IED>>>>
IED>>>>ST-K -
IED>>>>TR-K -
LEDs IED>>>>
IED>>>>ST-L -
IED>>>>TR-L -
IED>>> Enable OFF
IEDCLP>>> Mode OFF
tEDCLP>>> 0.10 s
tED>>>RES 0.00 s
IED>>>def OFF
1.00 IEn2
UED>>>def 0.100 UEn
ThetaE>>>def 60 gr
BetaE>>>def 45 gr
IEDCLP>>>def 1.5 IEn2
tED>>>def 1.00 s
IED>>>BLK1 OFF
IED>>>BLK2IN OFF
IED>>>BLK2OUT OFF
IED>>>BLK4 OFF
IED>>>BF OFF
IED>disIED>>> OFF
IED>>disIED>>> OFF
Relays IED>>>
IED>>>ST-K -
IED>>>TR-K -
LEDs IED>>>
IED>>>ST-L -
IED>>>TR-L -
IED>> Element >>
IED>>> Element >>
IED>>>> Element >>
Mode67N I
3VoType67N UE
Insens-Zone OFF
M 1.5
74VTint67N OFF
74VText67N OFF
