5.2 Functionality overview DPC10 DISPLAY
■ Speed display (including real time speed (SPEED), top speed (MAXS) and average
speed (AVG), switch between km and miles)
■ Switching between km and miles
■ Battery capacity indicator
■ Automatic sensors for lighting system
■ Brightness setting for backlight
■ Assist level indicator
■ Walk assist
■ Mileage (including single trip distance, total distance)
■ Display of the remaining range (depending on your riding style)
■ Engine power indicator
■ Energy consumption indicator in calories (note: if the display has this functionality)
■ Display of error messages
■ Maintenance
■ USB charging function
5.2.1 Overview control panelDPC10
1: Real-time display of battery capacity.
2: Menu.
3: Maintenance: see section 'Maintenance'.
4: Digital speed display.
5: Speed mode, top speed (MAXS) -
average speed (AVG).
6: Mileage, daily mileage
(TRIP) - total kilometres (TOTAL).
7: Data: display the data of the current
mode.
8: Walk assist.
9: The USB charging indicator displays the icon
if an external USB device is connected to the
display.
10: The display shows this symbol when the
lighting is switched on.
11: Error indicator.
12: Error code indicator.
13: Speed unit.
14: Unit indicator.
15: Remaining range (RANGE).
(this representation is not accurate)
16: Assist level
