8-2
8 LAYOUT
● Layout menu operation
By pressing the [MENU] key, the instrument will be in MENU 1/3 mode.
Press the [F2](LAYOUT) key, the menu of layout 1/2 will be shown.
[MENU]
[F2]
Normal measurement mode
MENU 1/3
F1:DATA COLLECT
F2:LAYOUT
F3:MEMORY MGR. P
↓
SELECT A FILE
FN:_________
INPUT LIST SKP ENTER
Selecting a file for LAYOUT
[F1](INPUT) : Input a new file name.
[F2](LIST) : Seek for a file.
[F3](SKP) : If you do not want to create or reselect a file.
[F4](ENTER) : To select display file.
LAYOUT 1/2
F1:OCC.PT INPUT
F2:BACKSIGHT
F3:LAYOUT P
↓
LAYOUT MENU 1/2
[ESC] [F1]
[F2]
[F3]
LAYOUT 2/2
F1:SELECT A FILE
F2:NEW POINT
F3:GRID FACTOR P
↓
LAYOUT MENU 2/2
[F4]
[ESC]
[F3]/[F4]
OCC.PT INPUT
BACKSIGHT
OCC.PT
PT#:__________
INPUT LIST NEZ ENTER
BACKSIGHT
PT#:__________
INPUT LIST NE/AZ ENT
DATA INPUT
LAYOUT
PT#:__________
INPUT LIST NEZ ENTER
SELECT A FILE
SELECT A FILE
FN:__________
INPUT LIST ––– ENTER
[ESC] [F1]
[F2]
[F3]
NEW POINT
NEW POINT
F1:SIDE SHOT
F2:RESECTION
GRID FACTOR
GRID FACTOR
=1.000000
>MODIFY? [YES][NO]
