9-16
9 MEMORY MANAGER MODE
9.7.2 Loading Data
Coordinate data files and PCODE Library data can be loaded from PC.
Example: Loading a coordinate data file
Operating procedure Operation Display
1
Press the [F3](MEMORY MGR.) key from the
menu 1/3.
[F3]
2
Press the [F4](P
↓
) key twice.
[F4]
[F4]
3
Press the [F1](DATA TRANSFER) key.
[F1]
4
Press the [F2](RS-232C) key.
[F2]
5
Press the [F4](ENT) key .
[F4]
6
Press the [F1](GTS FORMAT) key .
[F1]
7
Press the [F2](LOAD DATA) key.
[F2]
8
Select the type of data to load by pressing
[F1] or [F2] key.
Example : [F1](COORD. DATA)
[F1]
9
Press the [F1](INPUT) key and enter New File
Name you want to receive. Press the [F4](ENT)
key. *1)
[F1]
Enter FN
[F4]
10
Press the [F3](YES) key.*2)
The loading starts.
The display will return to menu.
[F3]
*1) Refer to Section 2.6 “How to Enter Alphanumeric characters”.
*2) To cancel the loading, press the [F4](STOP) key.
MEMORY MGR. 1/3
F1:FILE STATUS
F2:SEARCH
F3:FILE MAINTAN P
↓
MEMORY MGR. 3/3
F1:DATA TRANSFER
F2:INITIALIZE
P
↓
SELECT COM
[F1:BLUETOOTH]
F2:RS-232C
ENTER
SELECT COM
F1:BLUETOOTH
[F2:RS-232C]
ENTER
DATA TRANSFER
F1:GTS FORMAT
F2:SSS FORMAT
DATA TRANSFER
F1:SEND DATA
F2:LOAD DATA
F3:COMM. PARAMETERS
LOAD DATA
F1:COORD. DATA
F2:PCODE DATA
COORD. FILE NAME
FN:_________
INPUT ––– ––– ENTER
LOAD COORD. DATA
>OK ?
––– ––– [YES][NO]
LOAD COORD. DATA
< Loading Data!>
STOP
To Next Page
Loading...
