6 SPECIAL MODE (Menu Mode)
6.3 Setting Illumination of Display and Cross Hairs
Setting ON/OFF/LEVEL (1 to 9) for illumination of display (LCD) and reticle.
Setting LEVEL (1 to 9) is only for reticle.
[Example setting] LEVEL:2 and turn on the illumination.
3
Press the [F3](YES) key.
4
Press the [F1] (INPUT) key and enter Elevation.
*1) Press the [F4](ENT) key.
[F3]
[F1]
Enter ELEV.
[F4]
5
Enter Scale Factor in the same way.
[F1]
Enter Scale
[F4]
Grid Factor is displayed for 1 to 2 second and
display returns to menu.
*1) Refer to Section 2.6 “How to Enter Alphanumeric characters”.
● Input Range :Elevation : –9,999 to +9,999 meter (–32,805 to +3,2805 ft, ft+in)
Scale Factor: 0.990000 to 1.010000
Operating procedure Operation Display
1
After pressing the [MENU] key, press the [F4](P
↓
)
key to get the menu on page 2.
[MENU]
[F4]
2
Press the [F3] key.
The data previously set is shown.
[F3]
3
Press the [F3](LEVEL) key.
4
Press the [F2](
↑
) key, and then press the
[F4](ENTER) key.
[F3]
[F2]
[F4]
5
Press the [F1](ON) key.
[F1]
● To return to previous mode, press the [ESC] key.
GRID FACTOR
ELEV.→1000 m
SCALE:0.999000
INPUT ––– ––– ENTER
1234 5678 90. –[ENT]
GRID FACTOR
ELEV.:2000 m
SCALE
→
1.001000
INPUT ––– ––– ENTER
GRID FACTOR
=1.000686
MENU 2/3
F1:PROGRAMS
F2:GRID FACTOR
F3:ILLUMINATION P
↓
ILLUMINATION [OFF:1]
F1:ON
F2:OFF
F3:LEVEL
ILLUMINATION [OFF:1]
[LEVEL MODE]
↓
↑ ––– ENTER
ILLUMINATION [OFF:2]
F1:ON
F2:OFF
F3:LEVEL
ILLUMINATION [ON:2]
F1:ON
F2:OFF
F3:LEVEL
