Topcon GPT-3000W Series User Manual

8-6
8 LAYOUT
● Example setting :Setting Instrument point coordinates directly
Operating procedure Operation Display
1
Press the [F1](OCC.PT INPUT) key from the
Layout menu 1/2.
The previous data is shown.
[F1]
2
Press the [F3] (NEZ) key.
[F3]
3
Press the [F1](INPUT) key and enter
coordinate value.
press the [F4](ENT) key. *1)
[F1]
Enter coord.
[F4]
4
Press the [F1](INPUT) key and enter PT#.
Press the [F4](ENT) key. *2)
[F1]
Enter PT#
[F4]
5
Enter Instrument Height in the same way.
The display returns to layout menu 1/2.
[F1]
Enter
INS.HT
[F4]
*1) Refer to Section 2.6 “How to Enter Alphanumeric characters”.
*2) It is possible to record the coordinate value. Refer to Chapter 16 “SELECTING MODE”.
OCC.PT
PT#:
INPUT LIST NEZ ENTER
N
→
0.000 m
E: 0.000 m
Z: 0.000 m
INPUT --- PT# ENTER
COORD.DATA INPUT
PT#:
INPUT ––– ––– ENTER
1234 5678 90.– [ENT]
INSTRUMENT HEIGHT
INPUT
INS.HT: 0.000 m
INPUT ––– ––– ENTER
1234 5678 90.– [ENT]
LAYOUT 1/2
F1:OCC.PT INPUT
F2:BACKSIGHT
F3:LAYOUT P
↓
