8-13
8 LAYOUT
6
Press the [F4](ENTER) key.
The file will be set .
[F4]
7
Press the [F1](INPUT) key, and enter the new
point name. *4)
Press the [F4](ENT) key.
[F1]
Enter PT#
[F4]
8
Enter reflector height in the same way.
[F1]
Enter R.HT
[F4]
9
Collimate the new point, and press the [F1]
(MEAS) key.
Distance measuring starts.
Collimate
[F1]
10
Press the [F3](YES) key.*5)
The name and coordinate value are stored into
COORD.DATA.
The input menu for next new point is displayed.
PT# is automatically incremented.
[F3]
*1) If you want to input file name directly, press the [F1](INPUT) key and enter a file name.
*2) When a file has been selected already, ‘*’ mark is indicated on left of current file name.
For the file discrimination mark (*, @, &), refer to Chapter 9.3 “FILE MAINTENANCE”.
*3) Data in a file shown with arrow can be searched by pressing [F2](SRCH) key.
*4) Refer to Section 2.6 “How to Enter Alphanumeric characters”.
*5) An error will be displayed when the internal memory is full.
SIDE SHOT
PT#:
INPUT SRCH ––– ENTER
REFLECTOR HEIGHT
INPUT
R.HT : 0.000 m
INPUT ––– ––– ENTER
REFLECTOR HEIGHT
INPUT
R.HT : 1.235 m
MEAS --- NP/P ---
HR: 123°40'20"
HD*[n] < m
VD: m
> Measuring...
< complete >
N : 1234.567 m
E : 123.456 m
Z : 1.234 m
>REC ? [YES][NO]
SIDE SHOT
PT#:NP-101
INPUT SRCH ––– ENTER
