Topcon GPT-3000W Series - Page 115

8-17
8 LAYOUT
● Viewing PT# LIST
You can see the PT# List and enter the data from the List, also you can see coordinate data of a point.
[Example: Executing Layout Mode]
Operating procedure Operation Display
1
While executing the LAYOUT mode, press the
[F2](LIST) key.
The arrow(
→
) indicates selected data.
[F2]
2
By pressing the following keys, the list will increase
or decrease.
[ ]or[ ]: Increasing or Decreasing one by
one.
[ ]or[ ] :By ten Increasing or Decreasing.
[]or[],
[]or[]
3
To show the coordinate of the selected data, press
the [F1](VIEW) key.
It is still possible to scroll the PT# data by pressing
[[ ]or[ ] key.
[F1]
4
Press the [ESC] key.
The display returns to the List.
[ESC]
5
Press the [F4] (ENTER) key.
The selected point number is set as PT#.
[F4]
● The operation of [F2]( SRCH) is same as the "SEARCH" in the MEMORY MANAGER MODE.
For more information, refer to Chapter 9 “MEMORY MANAGER MODE”.
LAYOUT
PT#:
INPUT LIST NEZ ENTER
[TOPCON ]
→
DATA-01
DATA-02
VIEW SRCH ––– ENTER
DATA-49
→
DATA-50
DATA-51
VIEW SRCH ––– ENTER
PT#

DATA-50
N

100.234 m
E

12.345 m
Z

1.678 m
DATA-49
→
DATA-50
DATA-51
VIEW SRCH ––– ENTER
REFLECTOR HEIGHT
INPUT
R.HT : 0.000 m
INPUT ––– ––– ENTER
