Topcon GPT-3000W Series User Manual

4-10
4 DISTANCE MEASUREMENT
After measuring, the result added offset value will
be shown.
6
Show the relative elevation of point P0.
● Each time pressing the [ ] key, horizontal
distance, relative elevation and slope distance are
shown in sequence.
[ ]
● Show coordinate of point P0.
[]
● To return to procedure
4
, press [F1](NEXT) key.
● To return to the previous mode, press [ESC] key.
● To select the Non-prism or Prism mode, press the [F3](NP/P) key after the step 4.
DISTANCE OFFSET
HR: 80°30'40"
HD* 10.000 m
NEXT --- --- ---
DISTANCE OFFSET
HR: 80°30'40"
VD: 11.789 m
NEXT --- --- ---
DISTANCE OFFSET
HR: 80°30'40"
SD: 11.789 m
NEXT --- --- ---
N : 12.345 m
E : 23.345 m
Z : 1.345 m
NEXT --- --- ---
