7-11
7 DATA COLLECTION
5
Press the [F1](MEAS) key.
Continuous measuring starts.
[F1]
6
Collimate point A0 using the horizontal motion
clamp and horizontal tangent screw.
Collimate A
0
7
Show the horizontal distance of point A0.
[]
8
Show the relative elevation of point A0.
Each time pressing [ ] key, horizontal distance ,
relative elevation and slope distance are shown in
sequence.
[]
9
Show N coordinate of point A0 or A1.
Each time pressing [ ] key, N,E and Z
coordinate are shown in sequence.
[]
10
Press the [F3](YES) key.
The data is recorded and the next measuring point
is displayed.
[F3]
OFFSET-MEASUREMENT
HR: 120°30'40"
HD*[n] < m
>measuring ...
OFFSET-MEASUREMENT
HR: 120°30'40"
SD* 12.345 m
>OK? [YES][NO]
OFFSET-MEASUREMENT
HR: 123°30'40"
SD: 12.345 m
>OK? [YES][NO]
OFFSET-MEASUREMENT
HR: 123°30'40"
HD: 6.543 m
>OK? [YES][NO]
OFFSET-MEASUREMENT
HR: 123°30'40"
VD: 0.843 m
>OK? [YES][NO]
OFFSET-MEASUREMENT
HR: 123°30'40"
N : –12.345 m
>OK? [YES][NO]
PT#
PT-12
PCODE :TOPCON
R.HT : 1.200 m
INPUT SRCH MEAS ALL
