7 DATA COLLECTION
5
Measure the second and third points in the same
way. *1)
Collimate
P2
[F1]
Collimate
P3
[F1]
The display changes to PT# input in the plane
offset measurement.
Input point number if necessary.
6
Press the [F4](MEAS) key.
The instrument calculates and displays coordinate
and distance value of cross point between
collimation axis and of the plane. *2)
[F4]
7
Collimate the edge (P0) of the plane. *3), 4)
Collimate
P0
8
To show the slope distance (SD), press the []
key.
● Each time pressing the [ ] key, horizontal
distance, relative elevation and slope distance are
shown in sequence.
● To show coordinate value of point P0, press the
[] key.
9
Press the [F3](YES) key. Next offset point number
will be displayed.
[F3]
10
To escape the measuring, press the [ESC] key.
The display returns to the next point number in
data collect mode.
[ESC]
*1) In case the calculation of plane was not successful by the measured three points, error displays. Start
measuring over again from the first point.
*2) Data display is the mode beforehand of offset measurement mode.
*3) Error will be displayed when collimated to the direction which does not cross with the determined plane.
*4) The reflector height of the target point P0 is set to zero automatically
