11. MEASUREMENT WITH AUTO TRACKING
66
*1: Pressing [AT On] when "Track Setting" is set to "None" will result in one of the following
operations being performed.
When "R.C." selected: Performs Turning operation then Auto Tracking
When "G.S." selected: Performs Auto Pointing then Auto Tracking
& Turning operation
The instrument locates the Remote Controller by detecting the laser beam output by the Remote
Controller, then starts Auto Pointing.
When Turning operation cannot be performed correctly, check if the handle is attached securely.
Also, clean the beam detector for Remote Controller and terminals of the handle.
C"4.2 Mode Structure L Beam detector for Remote Controller and Terminals (Handle)"
[<-RC]
Rotates in a counterclockwise direction (from the
point of view of the RC-Controller) then performs
Auto Pointing/Auto Tracking
Rotates in a
counterclockwise
direction (from the point
of view of the RC-
Controller) then performs
Auto Pointing
[RC->]
Rotates in a clockwise direction (from the point of
view of the RC-Controller) then performs Auto
Pointing/Auto Tracking
Rotates in a clockwise
direction (from the point
of view of the RC-
Controller) then performs
Auto Pointing
[RC Cont]
Nullifies the current measurement position then
continues Turning operation/Auto Tracking
Nullifies the current
measurement position
then continues Turning
operation
[AT On]
Performs Turning
operation then Auto
Tracking
Performs Auto Pointing
then Auto Tracking
Performs Auto Tracking
*1
