15
ASSEMBLY PROCEDURE
ASSEMBLY PROCEDURE
SECURING THE INSTRUMENT TYPE TABLE TOP
FITTING TO AUTOMATIC INSTRUMENT TABLE AIT-20
(except for USA and Canada)
/AIT-15
(allarea)
/AIT-16
(allarea)
1
Remove the cover of the instrument table. Remove the 3 screws of the cover (AIT-20
only: For details, refer to the instruction manual of AIT-20.)
2
Place the tabletop on the instrument table, and secure it with the 4 bolts attached to the
instrument table. To reverse the direction of the instrument table, remove the power sup-
ply from the bottom of the table top and secure it on the opposite side.
CAUTION
To prevent falling during use and movement, secure each unit.
Connect the power cable to the table outlet and power supply of the instrument
table. Place the excess cable inside the cover, and attach the cover.
To Next Page
