SPECIFICATIONS AND PERFORMANCE
SPECIFICATIONS AND PERFORMANCE
SPECIFICATIONS AND PERFORMANCE
SL-D7 SL-D8Z
Microscope unit
Type Galileo type
Magnification Drum, 5-step magnification Manual zooming
Magnification steps 6/10/16/25/40 10, 16 and 25 w/clicks
Overall magnification
(actual vision field)
6.37 (φ35.1mm)/
9.94 (φ22.5mm)/
15.87 (φ14.1mm)/
25.37 (φ8.8mm)/
39.62 (φ5.6mm)/
6.35 - 31.75 (φ35.2 - φ7mm)
Eyepiece lens
Magnification: 12.5x
Diopter adjustment range: -5D - +5D
Binocular tubes PD adjustment: 55 - 78mm
Illumination unit
Illumination field
Slit width: 0-14mm, can be altered gradually(14mm=circle)
Slit length: 14-1mm, can be altered gradually(14mm=circle)
Aperture diameter: φ14, 10, 5, 2, 1, 0.2
Slit direction
Vertical to horizontal, can be altered gradually
Inclination: 5/10/15/20
Side swing
Filter
Blue filter, red-free filter, amber filter,
UV cut filter (normal use), IR cut filter (normal use),
ND filter (13% transmission), heat insulation filter, exciter filter for
slit lamp*
1
, barrier filter for slit lamp*
2
Illumination lamp 12V, 30W halogen lamp
Chinrest/forehead rest unit
Forward-backward move-
ment
90mm
Right-left movement 100mm
Vertical movement 30mm
Amount of movement in
all directions
15mm
Amount of vertical move-
ment of chinrest
80mm
Fixation target*
3
Fixation target with diopter adjustment
Luminous fixation target
Fixation lamp LED (Red) or bulb (white)
