Toro 34215 - Emptying the Hopper

EmptyingtheHopper
1.Movethemachinetoalevelsurface,move
motion-controllevertotheNEUTRALposition,shut
offtheengine,andsettheparkingbrake.
2.Emptythehopperbyscoopingoutasmuchofthe
materialaspossible.
3.Removethe4thumbscrewsthatsecurethefrontcover
(belowtheimpeller)tothechassisandremovethe
cover(Figure26).
Figure26
1.Forwardcover3.Thumbscrew
2.Clipnut
4.Removethedrivepinthatsecuretheimpellertothe
shaftoftheimpellermotorandremovetheimpeller
fromtheshaft(Figure27andFigure28).
Figure27
1.Drivepin3.Impeller
2.Shaft
Figure28
5.Placeashallowpanundertheshaftoftheimpeller
motor(Figure28).
6.Openthehoppergateasfollows:
A.Pushthelockingsleeveforthegatecablerearward
andliftthecableupfromtheballstudofthe
rate-gatelinkage(Figure29).
