g033293
Figure30
1.Filterhead
4.Gasket(drainplug)
2.Gasket(bowl)
5.Draincap
3.Filterelement6.Bowl
3.Rotatethedraincapcounterclockwiseand
removeitfromthebowlofthepressurelter
(Figure30).
Note:Allowthebowltodraincompletely.
4.Rotatethebowlcounterclockwiseandremove
thelterhead(Figure30).
5.Removethepressurelterelement(Figure30).
6.Cleanthepressurelterelementwithclean
water.
Important:Replacethelterifitisdamaged
orcannotbecleaned.
7.Checkthegasketforthedrainplug(located
insidethebowl)andthegasketforbowl(located
insidethelterhead)fordamageandwear
(Figure30).
Important:Replaceanydamagedorworn
gasketsfortheplug,bowl,orboth.
8.Installthepressurelterelementintothelter
head(Figure30).
Note:Ensurethatthelterelementisrmly
seatedintothelterhead.
9.Installthebowlontothelterhead,andtighten
byhand(Figure30).
10.Assemblethedraincapontothettingatthe
bottomofthebowl,andtightenthecapbyhand
(Figure30).
CleaningtheOptionalNozzle
Filters
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,shutoffthesprayerpump,shut
offtheengine,andremovethekey.
2.Removethenozzlefromthesprayturret(Figure
31).
g209504
Figure31
1.Sprayturret
3.Nozzle
2.Nozzlelter
3.Removethenozzlelter(Figure31).
4.Cleanthenozzlelterwithcleanwater.
Important:Replacethelterifitisdamaged
orcannotbecleaned.
5.Installthenozzlelter(Figure31).
Note:Ensurethatthelterisfullyseated.
6.Installthenozzleontothesprayturret(Figure
31).
7.Repeatsteps2through6fortheotherspray
nozzles.
38
