1
InstallingtheRearWheels
Partsneededforthisprocedure:
2Wheelassembly
Procedure
1.Attherearofthemachine,removethe4lugnuts
thatsecuretherearofthemachinetobrackets
oftheshippingpallet.
2.Assembleawheelassemblyontoeach
rear-wheelhubwiththe4lugnuts(Figure3).
g010018
Figure3
1.Wheelassembly2.Lugnut
3.Torquethelugnutsto61to75N∙m(45to55
ft-lb).
4.Repeatsteps1though3attheothersideof
themachine.
5.Deatealltiresto83kPa(12psi).
2
InstallingtheHandle
Partsneededforthisprocedure:
1Handle
3
Locknut(1/2inch)
AssemblingtheHandletothe
Machine
1.Insertthestudsattheendofthehandlebarinto
theholesinthesteeringarm(Figure4).
Note:Haveanotherpersonhelpholdthe
handlebar.
g358119
Figure4
1.Handlebar
3.Steeringarm
2.Stud4.Flangelocknuts(1/2inch)
2.Threadaangelocknut(1/2inch)ontoeachof
the3studs.
3.Torquetheangelocknutsto91to113N∙m(67
to83ft-lb).
4.Rotatethehandlebarupandsecureitwiththe
handlebar-latchpin(Figure5).
g342477
Figure5
1.Handlebar-latchpin3.Handlebar-latchknob
2.Detentplate
12
