Service Procedure Icons
The following icons appear throughout this Service Manual to bring attention to
specic important details of a service procedure.
Critical Process
This icon is used to highlight:
• Installing safety equipment (shields, guards, seat belts, brakes, and R.O.P .S.
components) that may have been removed
• Dimensions or settings that must be maintained for proper machine operation
• A specic fastener tightening sequence
• Component orientation that may not be obvious
Critical T orque
This icon is used to highlight an assembly torque requirement that is dif ferent
than what is recommended in the Standard T orque T ables.
Fluid Specications
This icon is used to highlight uid specications and capacities that are less
common, and may not appear on the machine service decal or in the machine
Operator ’ s Manual.
Note: Refer to the service decal on the machine and the machine Operator ’ s
Manual for commonly used uid specications and capacities.
Preface Page 4 2000 Series Z MASTER®Service Manual
3460-328 Rev A
