Toshiba e-studio2330c Service Handbook

e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C © 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved
SELF-DIAGNOSTIC MODE
2 - 74
487-0 Drive Fine
adjustment of
transfer belt
motor
rotational
speed
Transport
speed:
Normal
speed
PRT 128
<0-255>
M When the value
increases, the
reproduction ratio in the
secondary scanning
direction becomes
larger. (Approx. 0.1
mm/1 steps)
4
487-1 FAX 128
<0-255>
M4
487-2 PPC 128
<0-255>
M4
487-3 Transport
speed:
Decelerati
ng
PRT 128
<0-255>
M4
487-4 FAX 128
<0-255>
M4
487-5 PPC 128
<0-255>
M4
487-6 Transport
speed:
High
speed
PRT 128
<0-255>
M4
487-7 FAX 128
<0-255>
M4
487-8 PPC 128
<0-255>
M4
489-0 Drive Fine
adjustment of
feed/transport
motor
rotational
speed
Transport
speed:
Normal
speed
PRT 136
<0-255>
M4
489-1 FAX 128
<0-255>
M4
489-2 PPC 128
<0-255>
M4
489-3 Transport
speed:
Decelerati
ng
PRT 128
<0-255>
M4
489-4 FAX 128
<0-255>
M4
489-5 PPC 128
<0-255>
M4
489-6 Transport
speed:
High
speed
PRT 128
<0-255>
M4
489-7 FAX 128
<0-255>
M4
489-8 PPC 128
<0-255>
M4
498-0 Image Adjustment of
primary
scanning
laser writing
start position
for duplex
printing
Long size ALL 128
<0-255>
M When the value
increases by “1”, the
image shifts toward the
front side by 0.0423
mm.
Wh
en the value of 498-
0 is set, the same one
is automatically applied
to 498-1.
4
498-1 Short size
(A4/LT or
shorter)
ALL 128
<0-255>
M4
4719 Color
registrati
on
Color registration
adjustment
ALL - M Forcibly performs the
color registration
control adjustment in
order to eliminate the
color deviation of Y, M,
C and K colors.
6
4720 Color
registrati
on
Displaying parameters for
color registration
adjustment detection
abnormality
ALL -
<0-255>
M Checks the cause of a
“CA00” error when it
occurs.
2
Adjustment mode (05)
Code
Classific
ation
Items
Functi
on
Default
<Accept
able
value>
RAM Contents
Proce
dure
