6
© 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C
ERROR CODE AND TROUBLESHOOTING
6 - 85
[CCD0] Stack ejection motor abnormality
[CCE0] Rear end assist motor abnormality
[CCF0] Gear change motor abnormality
MJ-1030
Is the shutter home position sensor (PI45) normal?
 NO  Replace the sensor.
YES
Are the wirings between the finisher controller PC board and the stack ejection motor (M32)/
shutter clutch (CL31) correct?
 NO  Correct the wirings.
YES
Is there any problem with the shutter mechanism?
 YES Fix the shutter mechanism.
NO
1. Replace the stack ejection motor and shutter clutch.
2. Replace the finisher controller PC board.
MJ-1030
Is the rear end assist guide home position sensor (PI39) normal?
 NO  Replace the sensor.
YES
Is the wiring between the finisher controller PC board and the rear end assist motor (M39)
correct?
 NO  Correct the wiring.
YES
Is there any problem with the rear end assist mechanism?
 YES Fix the rear end assist mechanism.
NO
1. Replace the rear end assist motor.
2. Replace the finisher controller PC board.
MJ-1030
Is the gear change home position sensor (PI49) normal?
 NO  Replace the sensor.
YES
Is the wiring between the finisher controller PC board and the gear change motor (M40)
correct?
 NO  Correct the wiring.
YES
Is there any problem with the gear change mechanism?
 YES Fix the gear change mechanism.
NO
1. Replace the gear change motor.
2. Replace the finisher controller PC board.
To Next Page
