SELF-DIAGNOSTIC MODE
2 - 8
[6]
A- --
B- --
C- --
D APS sensor (APS-R) Original present No original
E APS sensor (APS-C) Original present No original
F APS sensor (APS-3) Original present No original
G APS sensor (APS-2) Original present No original
H APS sensor (APS-1) Original present No original
[7]
A RADF tray sensor Original present No original
B RADF empty sensor Original present No original
C RADF jam access cover sensor Cover opened Cover closed
D RADF open/close sensor RADF opened RADF closed
E RADF exit sensor Original present No original
F RADF intermediate sensor Original present No original
G RADF read sensor Original present No original
H RADF registration sensor Original present No original
[8]
A RADF original tray width sensor (TWID0S)
(Refer to table2)
OFF(H) ON(L)
B RADF original tray width sensor (TWID1S)
(Refer to table2)
OFF(H) ON(L)
C RADF original tray width sensor (TWID2S)
(Refer to table2)
OFF(H) ON(L)
D- --
E RADF original length sensor Original present No original
F RADF original width sensor 1 Original present No original
G RADF original width sensor 2 Original present No original
H- --
[9]
A- --
B- --
C- --
D- --
E Needle electrode cleaner detection sensor Cleaner limit
position
Other than cleaner
limit position
F- --
G- --
H- --
[0]
A- --
B Side cover open/close switch Cover opened Cover closed
C- --
D- --
E Drum mode detection signal Color Black
F- --
G Fuser unit connection Connected Not connected
H Key copy counter connection Not connected Connected
Digital
key
Button Items to check
Contents
Highlighted display
e.g.
Normal display
e.g.
