© 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C
SELF-DIAGNOSTIC MODE
2 - 9
Table 1. Relation between the status of the bypass paper width sensor and paper size (width).
Table 2. Relation between the status of the original tray width sensor and paper size (width).
H (= high level): Open L (= low level): Short
Bypass paper width sensor
Paper width size
3210
0111 A3/LD
1011 A4-R/LT-R
1101 A5-R/ST-R
1110 Card size
0011 B4-R/LG
1001 B5-R
Original tray width sensor
Paper width size
(LT series)
Paper width size
(A4 series)
TWID2S TWID1S TWID0S
H H H LD / LT A3 / A4
HHL - B5-R
HLH ST-R A5-R
L H H LD / LT A3 / A4
L H L - Postcard
L L H 8.5x8.5 / LT-R /
KLG / 13"LG
A4-R / FOLIO
L L L COMPUTER B4 / B5
