Toshiba e-studio2330c Service Handbook

e-STUDIO2020C/2330C/2820C/2830C/3520C/3530C/4520C © 2008 - 2011 TOSHIBA TEC CORPORATION All rights reserved
SELF-DIAGNOSTIC MODE
2 - 10
[FAX] button: OFF/[COPY] button: ON ([FAX] LED: OFF/[COPY] LED: ON)
Digital
key
Button Items to check
Contents
Highlighted display
e.g.
Normal display
e.g.
[1]
- Temperature/humidity sensor (displays
temperature inside of the equipment)
- Temperature [°C]
[2]
- Temperature/humidity sensor (displays humidity
inside of the equipment)
- Humidity [%RH]
[3]
- Drum thermistor-K
(displays temperature on the drum surface of K
color)
- Temperature [°C]
[4]
- Drum thermistor-Y
(displays temperature on the drum surface of Y
color)
- Temperature [°C]
[5]
A- --
B- --
C- --
D- --
E- --
F- --
G- --
H- --
[6]
A- --
B- --
C- --
D- --
E- --
F- --
G- --
H- --
[7]
A- --
B- --
C- --
D- --
E- --
F- --
G- --
H- --
[8]
A- --
B- --
C- --
D- --
E- --
F- --
G- --
H- --
[9]
A- --
B- --
C- --
D- --
E- --
F- --
G- --
H- --
