Replacement Procedures
エラー
!
4-52 [CONFIDENTIAL] QOSMIO F60 Maintenance Manual (960-796)
Installing the Hinge cover
To install the hinge cover, follow the steps below and refer to Figure 4-30.
1. Set the hinge cover to the base assembly while engaging the latches.
NOTE: When setting the hinge cover, be careful not to pinch the harnesses.
2. Secure the hinge cover with the following screws.
M2.56B FLAT HEAD screw 3
