Toshiba Qosmio F60 Series Maintenance Manual

エラー ! スタイルが定義されていません。 エラー ! スタイルが定義されていません。
エラー ! スタイルが定義されていません。 Replacement Procedures エラー !
ス
4.21 Brake hinge LOW R
Removing the Brake hinge LOW R
To remove the brake hinge LOW R, follow the steps below and refer to Figure 4-31.
1. Remove the following screw securing the brake hinge LOW R.
 M2.56C Tapping screw 1
2. Remove the brake hinge LOW R.
M2.5x6C Tapping
Brake hinge LOW R
Figure 4-31 Removing the brake hinge LOW R
Installing the Brake hinge LOW R
To install the brake hinge LOW R, follow the steps below and refer to Figure 4-31.
1. Set the brake hinge LOW R in place and secure it with the following screw.
 M2.56C Tapping screw 1
QOSMIO F60 Maintenance Manual (960-796) [CONFIDENTIAL] 4-53

Toshiba Qosmio F60 Series Specifications

General

Operating System	Windows 7 Home Premium
Storage	500GB HDD
Webcam	Integrated Webcam
Audio	Harman/Kardon stereo speakers
Connectivity	Wi-Fi 802.11n, Bluetooth
Ports	HDMI, VGA, eSATA, Ethernet
Battery	6-cell Lithium-ion battery
Processor	Intel Core i3 / i5 / i7 (depending on the specific model)
