Toshiba Qosmio F60 Series

エラー ! スタイルが定義されていません。 エラー ! スタイルが定義されていません。
エラー ! スタイルが定義されていません。 Replacement Procedures エラー !
ス
4.32 Wireless LAN antenna/Camera harness
Removing the Wireless LAN antenna/Camera harness
To remove the wireless LAN antenna/camera harness, follow the steps below and refer to
Figure 4-56.
1. Turn up the insulators and remove the camera harness.
2. Peel off the wireless LAN antennas from the LCD cover.
Wireless LAN antenna (white)
LCD cover
Wireless LAN antenna (
black)
Wireless LAN
antenna cable
Camera harness
Insulator
Figure 4-56 Removing the wireless LAN antenna/camera harness
NOTE: Do not reuse the removed wireless LAN antenna. Be sure to use new wireless
LAN antennas.
Please prepare required parts in advance, when replacing the following item.
Parts List
ITEM No
PART NAME
Quantity ITEM
LCD COVER LCD COVER ASSY 1
QOSMIO F60 Maintenance Manual (960-796) [CONFIDENTIAL] 4-91
