Appendices Appendix C Pin Assignments
C-2 [CONFIDENTIAL] Qosmio F60 Serise Maintenance Manual (960-796)
Table C-1 Memory A connector (200-pin) (2/3)
Pin No. Signal Name Pin No. Signal Name
61 GND 62 ADQS3-B1N
63 ADM3-B1P 64 ADQS3-B1P
65 GND 66 GND
67 ADQ26-B1P 68 ADQ30-B1P
69 ADQ31-B1P 70 ADQ27-B1P
71 GND 72 GND
73 ACKE0-B1P 74 ACKE1-B1P
75 1R5-B1V 76 1R5-B1V
77 NC 78 AMA15-B1P
79 ABS2-B1P 80 AMA14-B1P
81 1R5-B1V 82 1R5-B1V
83 AMA12-B1P 84 AMA11-B1P
85 AMA09-B1P 86 AMA07-B1P
87 1R5-B1V 88 1R5-B1V
89 AMA08-B1P 90 AMA06-B1P
91 AMA05-B1P 92 AMA04-B1P
93 1R5-B1V 94 1R5-B1V
95 AMA03-B1P 96 AMA02-B1P
97 AMA01-B1P 98 AMA00-B1P
99 1R5-B1V 100 1R5-B1V
101 XACK0-B1P 102 XACK1-B1P
103 XACK0-B1N 104 XACK1-B1N
105 1R5-B1V 106 1R5-B1V
107 AMA10-B1P 108 ABS1-B1P
109 ABS0-B1P 110 ARAS-B1N
111 1R5-B1V 112 1R5-B1V
113 AWE-B1N 114 ACS0-B1N
115 ACAS-B1N 116 AODT0-B1P
117 1R5-B1V 118 1R5-B1V
119 AMA13-B1P 120 AODT1-B1P
121 ACS1-B1N 122 NC
123 1R5-B1V 124 1R5-B1V
125
NC（TEST）
126
MRVREF－B0V
127 GND 128 GND
129 ADQ32-B1P 130 ADQ36-B1P
131 ADQ33-B1P 132 ADQ37-B1P
To Next Page
