Page #425 background image
Appendix C Pin Assignments Appendices
Qosmio F60 Series Maintenance Manual (960-796) [CONFIDENTIAL] C-3
Table C-1 Memory A connector (200-pin) (3/3)
Pin No. Signal Name Pin No. Signal Name
133 GND 134 GND
135 ADQS4-B1N 136 ADM4-B1P
137 ADQS4-B1P 138 GND
139 GND 140 ADQ38-B1P
141 ADQ34-B1P 142 ADQ39-B1P
143 ADQ35-B1P 144 GND
145 GND 146 ADQ41-B1P
147 ADQ44-B1P 148 ADQ40-B1P
149 ADQ45-B1P 150 GND
151 GND 152 ADQS5-B1N
153 ADM5-B1P 154 ADQS5-B1P
155 GND 156 GND
157 ADQ47-B1P 158 ADQ46-B1P
159 ADQ42-B1P 160 ADQ43-B1P
161 GND 162 GND
163 ADQ53-B1P 164 ADQ52-B1P
165 ADQ49-B1P 166 ADQ48-B1P
167 GND 168 GND
169 ADQS6-B1N 170 ADM6-B1P
171 ADQS6-B1P 172 GND
173 GND 174 ADQ50-B1P
175 ADQ54-B1P 176 ADQ51-B1P
177 ADQ55-B1P 178 GND
179 GND 180 ADQ56-B1P
181 ADQ60-B1P 182 ADQ61-B1P
183 ADQ57-B1P 184 GND
185 GND 186 ADQS7-B1N
187 ADM7-B1P 188 ADQS7-B1P
189 GND 190 GND
191 ADQ62-B1P 192 ADQ58-B1P
193 ADQ59-B1P 194 ADQ63-B1P
195 GND 196 GND
197 GND 198 TSDIM-P3N
199 P3V 200 SMBDT1-P3P
201 GND 202 SMBCK1-P3P
203 0R75-P0V 204 0R75-P0V
1T GND 2T GND
