Toshiba Qosmio F60 Series Maintenance Manual

Appendix C Pin Assignments Appendices
Qosmio F60 Series Maintenance Manual (960-796) [CONFIDENTIAL] C-5
Table C-2 Memory B connector (200-pin) (2/3)
Pin No. Signal Name Pin No. Signal Name
61 GND 62 BDQS3-B1N
63 BDM3-B1P 64 BDQS3-B1P
65 GND 66 GND
67 BDQ26-B1P 68 BDQ31-B1P
69 BDQ27-B1P 70 BDQ30-B1P
71 GND 72 GND
73 BCKE0-B1P 74 BCKE1-B1P
75 1R5-B1V 76 1R5-B1V
77 NC 78 BMA15-B1P
79 BBS2-B1P 80 BMA14-B1P
81 1R5-B1V 82 1R5-B1V
83 BMA12-B1P 84 BMA11-B1P
85 BMA09-B1P 86 BMA07-B1P
87 1R5-B1V 88 1R5-B1V
89 BMA08-B1P 90 BMA06-B1P
91 BMA05-B1P 92 BMA04-B1P
93 1R5-B1V 94 1R5-B1V
95 BMA03-B1P 96 BMA02-B1P
97 BMA01-B1P 98 BMA00-B1P
99 1R5-B1V 100 1R5-B1V
101 XBCK0-B1P 102 XBCK1-B1P
103 XBCK0-B1N 104 XBCK1-B1N
105 1R5-B1V 106 1R5-B1V
107 BMA10-B1P 108 BBS1-B1P
109 BBS0-B1P 110 BRAS-B1N
111 1R5-B1V 112 1R5-B1V
113 BWE-B1N 114 BCS0-B1N
115 BCAS-B1N 116 BODT0-B1P
117 1R5-B1V 118 1R5-B1V
119 BMA13-B1P 120 BODT1-B1P
121 BCS1-B1N 122 NC
123 1R5-B1V 124 1R5-B1V
125
NC（TEST）
126
MRVREF－B0V
127 GND 128 GND
129 BDQ33-B1P 130 BDQ36-B1P
131 BDQ32-B1P 132 BDQ37-B1P

Toshiba Qosmio F60 Series Specifications

General

Operating System	Windows 7 Home Premium
Storage	500GB HDD
Webcam	Integrated Webcam
Audio	Harman/Kardon stereo speakers
Connectivity	Wi-Fi 802.11n, Bluetooth
Ports	HDMI, VGA, eSATA, Ethernet
Battery	6-cell Lithium-ion battery
Processor	Intel Core i3 / i5 / i7 (depending on the specific model)
