Appendices Appendix C Pin Assignments
C-6 [CONFIDENTIAL] Qosmio F60 Serise Maintenance Manual (960-796)
Table C-2 Memory B connector (200-pin) (3/3)
Pin No. Signal Name Pin No. Signal Name
133 GND 134 GND
135 BDQS4-B1N 136 BDM4-B1P
137 BDQS4-B1P 138 GND
139 GND 140 BDQ39-B1P
141 BDQ34-B1P 142 BDQ38-B1P
143 BDQ35-B1P 144 GND
145 GND 146 BDQ41-B1P
147 BDQ40-B1P 148 BDQ44-B1P
149 BDQ45-B1P 150 GND
151 GND 152 BDQS5-B1N
153 BDM5-B1P 154 BDQS5-B1P
155 GND 156 GND
157 BDQ46-B1P 158 BDQ43-B1P
159 BDQ47-B1P 160 BDQ42-B1P
161 GND 162 GND
163 BDQ49-B1P 164 BDQ53-B1P
165 BDQ48-B1P 166 BDQ52-B1P
167 GND 168 GND
169 BDQS6-B1N 170 BDM6-B1P
171 BDQS6-B1P 172 GND
173 GND 174 BDQ50-B1P
175 BDQ54-B1P 176 BDQ51-B1P
177 BDQ55-B1P 178 GND
179 GND 180 BDQ61-B1P
181 BDQ57-B1P 182 BDQ56-B1P
183 BDQ60-B1P 184 GND
185 GND 186 BDQS7-B1N
187 BDM7-B1P 188 BDQS7-B1P
189 GND 190 GND
191 BDQ59-B1P 192 BDQ58-B1P
193 BDQ63-B1P 194 BDQ62-B1P
195 GND 196 GND
197 GND 198 TSDIM-P3N
199 P3V 200 SMBDT1-P3P
201 P3V 202 SMBCK1-P3P
203 0R75-P0V 204 0R75-P0V
1T GND 204 GND
