4 Replacement Procedures 4.1 Overview
NOTE: 1. A TV tuner, GPS or Wireless USB is incorporated exclusively in the PCI-
mini card slot3. (GPS and Wireless USB may be incorporated in future.)
2. A MDC or FM tuner is incorporated exclusively
3. Depending on a used VGA type, there are following combinations.
Please prepare required parts in advance, when replacing the following item.
ITEM
Parts List
ITEM No
PART NAME Quantity
50 COVER ASSY 1
27 9 BUTTON TOUCH SENSOR 1
39 TOUCH PAD 1
COVER ASSY
89 T-PAD BACK INSULATOR 1
ITEM
Parts List
ITEM No
PART NAME Quantity
51 LCD COVER ASSY 1
47 CAMERA MODULE 1
LCD COVER
ASSY
73 2.4/5.2GHZ ANTENNA 1
Parts which can not be reused are (1) Touch sensor (9 BUTTON TOUCH SENSOR), (2)
Touch pad, (3) Camera module and (4) Wireless LAN antenna (2.4/5.2GHZ ANTENNA).
