Toshiba QOSMIO G50 Maintenance Manual

Appendix C Pin Assignments Appendices
Qosmio G50 Maintenance Manual (960-683) [CONFIDENTIAL] C-1
Appendix C Pin Assignments
System board (FDUSY＊)
C.1 CN1400 Memory A connector(200-pin)
Table C-1 Memory A connector (200-pin) (1/3)
Pin No. Signal Name Pin No. Signal Name
1 MRVREF-B0V 2 GND
3 GND 4 ADQ05-B1P
5 ADQ00-B1P 6 ADQ01-B1P
7 ADQ04-B1P 8 GND
9 GND 10 ADM0-B1P
11 ADQS0-B1N 12 GND
13 ADQS0-B1P 14 ADQ02-B1P
15 GND 16 ADQ03-B1P
17 ADQ07-B1P 18 GND
19 ADQ06-B1P 20 ADQ08-B1P
21 GND 22 ADQ09-B1P
23 ADQ12-B1P 24 GND
25 ADQ13-B1P 26 ADM1-B1P
27 GND 28 GND
29
ADQS1-B1N
30
XMCK0-B1P
31
ADQS1-B1P
32
XMCK0-B1N
33 GND 34 GND
35 ADQ11-B1P 36 ADQ15-B1P
37 ADQ14-B1P 38 ADQ10-B1P
39 GND 40 GND
41 GND 42 GND
43 ADQ16-B1P 44 ADQ21-B1P
45 ADQ20-B1P 46 ADQ17-B1P
47 GND 48 GND
49 ADQS2-B1N 50 TSDIMA-P3N
51 ADQS2-B1P 52 ADM2-B1P
53 GND 54 GND
55 ADQ22-B1P 56 ADQ23-B1P
57 ADQ19-B1P 58 ADQ18-B1P
59 GND 60 GND
