Page #397 background image
Appendix C Pin Assignments Appendices
Qosmio G50 Maintenance Manual (960-683) [CONFIDENTIAL] C-19
C.20 CN3240 FDULE* board interface connector (30-pin)
Table C-20 FDULE* board interface connector (30-pin)
Pin No. Signal Name Pin No. Signal Name
1 GND 2 RCIRRX-S5P
3 RFLED-S5N 4 WMLED-S5N
5 P5V 6 LERNRX-P5N
7 PWLEBR-S3P 8 FMLED-P5N
9 RFSWON-S3N 10 RECRED-S5N
11
RECORG-S5N
12
SATLED-P5N
13
BAT1GR-S5N
14
BAT1OR-S5N
15
M5V
16
PWLEGR-S5N
17
PWLEOR-S5N
18
E3V
19
DCINGR-S5N
20
DCINOR-S5N
21
GND
22
FGSPON-S3N
23
GND
24
ZUSBP3-E3N
25
ZUSBP3-E3N
26
ZUSBP3-E3P
27
GND
28
GND
29
IPDDAT-P5P
30
IPDCLK-P5P
1T
GND
2T
GND
C.21 CN3300 Power SW connector (3-pin)
Table C-21 Power SW connector (3-pin)
Pin No. Signal Name Pin No. Signal Name
1 P5V 2 PWRSW-S3N
3
GND
C.22 CN3330 Volume interface connector (4-pin)
Table C-22 Volume interface connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1 P5V 2 ROTENB-S3N
3
ROTENA-S3N
4
GND
