Toshiba QOSMIO G50

Appendices Appendix C Pin Assignments
C-20 [CONFIDENTIAL] Qosmio G50 Maintenance Manual (960-683)
C.23 CN4230 IEEE1394 interface connector (4-pin)
Table C-23 IEEE1394 interface connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1 ZTPB0-P3N 2 ZTPB0-P3P
3
ZTPA0-P3N
4
ZTPA0-P3P
1T
GND
2T
GND
3T
GND
4T
GND
C.24 CN4440 Bluetooth2 interface connector (10-pin)
Table C-24 Bluetooth2 interface connector (10-pin)
Pin No. Signal Name Pin No. Signal Name
1 GND 2 GND
3 P3V 4
WCHDAT-P3P
5
BTRST-S3N
6
BTMDL-P3N
7
WCHCLK-P3P
8
ZUSBP7-E3N
9
ZUSBP7-E3P
10
GND
C.25 CN4612 USB(PORT0) interface connector (10-pin)
Table C-25 USB(PORT0) interface connector (10-pin)
Pin No. Signal Name Pin No. Signal Name
1 USB0PS-E5V 2 ZUSBP0-E3N
3 ZUSBP0-E3P 4
GND
1T
GND
2T
GND
3T
GND
4T
GND
