4 Replacement Procedures 4.29 VGA fan cover
4.29 VGA fan cover
Removing the VGA fan cover
The following describes the procedure for removing the VGA fan cover (See Figure 4-57).
1. Remove the VGA fan cover from the slot.
VGA fan cover
Figure 4-57 Removing the VGA fan cover
Installing the VGA fan cover
The following describes the procedure for installing the VGA fan cover (See Figure 4-57).
1. Set the VGA fan cover to the slot.
4-88 [CONFIDENTIAL] QOSMIO G50 Maintenance Manual (960-683)
