Toshiba QOSMIO G50

Appendices Appendix C Pin Assignments
C-30 [CONFIDENTIAL] Qosmio G50 Maintenance Manual (960-683)
C.42 CN9700 Left SPEAKER LED interface connector (3-pin)
Table C-42 Left SPEAKER interface connector (3-pin)
Pin No. Signal Name Pin No. Signal Name
1 GND 2 LEDPWR-P5V
3
GND
C.43 CN9701 Right SPEAKER LED interface connector (3-pin)
Table C-43 Right SPEAKER interface connector (3-pin)
Pin No. Signal Name Pin No. Signal Name
1 GND 2 LEDPWR-P5V
3
GND
C.44 J4100 LAN interface connector (8-pin)
Table C-44 LAN interface connector (8-pin)
Pin No. Signal Name Pin No. Signal Name
1 ZMDI0P-EYP 2 ZMDI0N-EYN
3
ZMDI1P-EYP
4
ZMDI2P-EYP
5
ZMDI2P-EYN
6
ZMDI1P-EYN
7
ZMDI3P-EYP
8
ZMDI3P-EYN
1T
GND
2T
GND
