4.3 ExpressCard/Bridge media 4 Replacement Procedures
4.3 ExpressCard/Bridge media
4.3.1 ExpressCard
Removing the ExpressCard
The following describes the procedure for removing the ExpressCard (See Figure 4-3).
CAUTION: Insert or remove an Express card in accordance with any instructions in
their manual or the manuals of the computer system you are using.
1. Open the left side cover and push the ExpressCard. It will pop out partly when you
release, so pull out the card.
ExpressCard
Left side cover
Figure 4-3 Removing the ExpressCard
Installing the ExpressCard
The following describes the procedure for installing the ExpressCard (See Figure 4-3).
1. Insert the ExpressCard and press it until it is securely connected.
QOSMIO G50 Maintenance Manual (960-683) [CONFIDENTIAL] 4-13
