4 Replacement Procedures 4.38 Fluorescent lamp
4.38.1 Replacing the 18.4-inch HD+ Samsung Fluorescent Lamp
To replace the 18.4-inch HD+ Samsung fluorescent lamp, follow the steps below and refer to
figures 4-76 to 4-79.
Disassembling the fluorescent lamp
1. Remove the PCB cover.
CAUTION: Handle with care not to damage COF of S/D.
PCB cover
Figure 4-76 Replacing Samsung fluorescent lamp (HD+) (1)
4-114 [CONFIDENTIAL] QOSMIO G50 Maintenance Manual (960-683)
