Appendix C Pin Assignments Appendices
Qosmio G50 Maintenance Manual (960-683) [CONFIDENTIAL] C-27
Table C-32 GFX interface connector (230-pin) (4/4)
Pin No. Signal Name Pin No. Signal Name
211 GND 212 LCDVEN-E5N
213 ZNDTX2-P3N 214 FLPWN-P3P
215 ZNDTX2-P3P 216 FLVEN-P3P
217 GND 218 NVESDA-P5P
219 ZNDTX1-P3N 220 NVESCL-P5P
221 ZNDTX1-P3P 222 NC
223 GND 224 GND
225 ZNDTX0-P3N 226 P3V
227 ZNDTX0-P3P 228 P3V
229 GND 230 P3V
C.33 CN6170 SPEAKER Right / subwoofer interface connector (4-
pin)
Table C-33 SPEAKER RIGHT interface connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1 SPOTR-PXN 2 SPOTR-PXP
3
WOOFER-PXP
4
WOOFER-PXN
C.34 CN6171 SPEAKER Left interface connector (2-pin)
Table C-34 SPEAKER LEFT interface connector (2-pin)
Pin No. Signal Name Pin No. Signal Name
1
SPOTL-PXP
2
SPOTL-PXN
