Appendices Appendix B Board Layout
B.10 NB9E board (FDUNE*) View
(front)
(back)
Figure B-
9
NB9E board (F
DUNE
*) layout (front
/back
)
Table B-
9
NB9E board
(
FDUNE
*) connector (
Front
)
Number Name
CN5960 System board I/F connector
B-12 [CONFIDENTIAL]
QOSMIO G50 Maintenance Manual (960-683)
