Toshiba QOSMIO G50 Maintenance Manual

Appendices Appendix C Pin Assignments
C-18 [CONFIDENTIAL] Qosmio G50 Maintenance Manual (960-683)
C.18 CN3011 FM Tuner interface connector (10-pin)
Table C-18 FM Tuner interface connector (10-pin)
Pin No. Signal Name Pin No. Signal Name
1 P5V 2 ZUSB10-E3N
3 ZUSB10-E3P 4 GND
5 NC 6 NC
7 GND 8 FMAUDL-PXP
9 GND 10 FMAUDR-PXP
1T
GND
2T
GND
C.19 CN3230 Keyboard interface connector (34-pin)
Table C-19 Keyboard interface connector (34-pin)
Pin No. Signal Name Pin No. Signal Name
1 NUMLED-P5N 2 NC
3 CAPLED-P5N 4 P5V
5 KBRT06-S3N 6 KBRT02-S3N
7 KBRT03-S3N 8 KBRT05-S3N
9 KBRT01-S3N 10 KBRT04-S3N
11
KBRT07-S3N
12
KBRT00-S3N
13
KBSC00-S3N
14
KBSC09-S3N
15
KBSC03-S3N
16
KBSC02-S3N
17
KBSC05-S3N
18
KBSC04-S3N
19
KBSC06-S3N
20
KBSC08-S3N
21
KBSC10-S3N
22
KBSC01-S3N
23
KBSC11-S3N
24
KBSC07-S3N
25
KBSC15-S3N
26
KBSC12-S3N
27
KBSC13-S3N
28
KBSC14-S3N
29
NC
30
NC
31
KBSC17-S3N
32
NC
33
KBSC16-S3N
34
P5V
1T
GND
2T
GND
