4.2 Battery pack 4 Replacement Procedures
5. Slide the battery latch in the direction of the arrow.
6. Insert your finger into the slit and pull up the battery pack to remove.
Battery latch
Battery pack
Slit
Figure 4-2 Removing the battery pack (2)
NOTE: Dispose of the used battery pack in accordance with the laws and ordinances of
your local authority.
QOSMIO G50 Maintenance Manual (960-683) [CONFIDENTIAL] 4-11
