4.5 Memory module 4 Replacement Procedures
3. Remove the memory module(s) while opening the left and right latches.
Memory module B
Latch
Latch
Memory module A
Figure 4-10 Removing the memory module
Installing the memory module
To install the memory module, make sure that the computer is in boot mode. Then perform
the following procedure (See Figure 4-9 and 4-10).
CAUTION: Be sure to install a memory module to slot A. The computer does not boot
when a memory module is not installed into the slot A.
Never press hard or bend a memory module.
1. Insert the memory module(s) into the connector on the computer slantwise and press
it to connect firmly.
CAUTION: After installing the memory module, make sure that the memory module is
secured with the left and right latches.
2. Install the memory cover and secure it with the screw.
3. When the power of the computer is turned on, the computer checks automatically the
memory size. Make sure that the new memory is detected correctly.
4. If the memory is not detected, check that it is connected correctly.
QOSMIO G50 Maintenance Manual (960-683) [CONFIDENTIAL] 4-21
